ABB Bailey DCS Infi 90 IMDSI22 Digital Input Module

Description

The IMDSI13, IMDSI14, and IMDSI22 Digital Input Modules provide 16 separate digital signals into the Symphony Enterprise Management and Control System for processing and monitoring. They interface process field inputs to the system. A contact closure or switch is an example of a device that supplies a digital signal. The controller provides the control functions, I/O modules provide the inputs and outputs. Three variations of the DSI modules are described in this instruction:

• IMDSI13 - 24 VDC inputs.

• IMDSI14 - 48 VDC inputs.

• IMDSI22 - 120 VAC, 24 VDC, 48 VDC, or 125 VDC inputs. Figure 1-1 shows a Harmony area controller and the Harmony rack controllers using the rack I/O modules for I/O interface.

Personnel installing, operating, or maintaining the DSI modules should read this instruction before performing any installation, operation, or maintenance procedures. Installation requires an engineer or technician with experience handling electronic circuitry. Those working with the digital output module should have experience working with and know the precautions to take around AC/DC power. A knowledge of the Symphony system and electronic principles is also require
