CMA120 3DDE300400 Basic Controller Panel ABB

Introduction

The CMA Series of commercial mixer/amplifiers combines a versatile 6-input mic/line mixer with either 30, 60, 120, or 350 Watt amplification. Mixing functions include mic/line/telephone inputs, selectable automatic & manual channel muting, channel priority assignment, remote level control, tone control, a built-in compressor, an internal chime, phantom power, and extensive output patching. The amplifier includes an output transformer, and provides rated power into direct or distributed speaker systems. The CMA Series carries a five-year warranty.

CMA Series features include:

♦ integrated mixer, power amplifier, and output transformer

♦ five electronically balanced microphone/line input channels

♦ one transformer balanced microphone/line/tel input channel

♦ rear panel trim control & pad switch on each input channel

♦ +24 Volt phantom power selectable on each input channel

♦ imput transformer option on mic/line inputs (except CMA350)

♦ automatic muting of selected channels (-10, -20, or -40dB)

♦ automatic muting triggered by selected "priority" channels

♦ manual muting of selected channels (-10, -20, or -40dB)

♦ manual muting triggered from remote contact closures

♦ remote control of master level via rear panel terminals

♦ integral output compressor with rear panel threshold control

♦ recessed treble & bass controls plus "loudness" & "low-cut"

♦ two insert points for signal processing and remote control

♦ two line-outs and one stack-in for system interconnections

♦ 30, 60, 120, or 350 Watts into direct or distributed systems

♦ front panel indicators for power, fault, signal, and peak

♦ internal 'pre-announcement' chime tone with level control

♦ input/output connections provided on barrier strip terminals

♦ integral security cover and removable rack-wing/handles

♦ covered by Biamp Systems' five-year warranty
