100% New ABBNTR002-A Module In Stock

Product Details

Dipswitch SW3 pole one determines network processing module compatibility. Set pole one to zero for a process control unit interface. Pole two enables or disables ROM checksumming. Elsag Bailey recommends that the NIS module be installed with checksumming enabled to take full advantage of the on-board diagnostics. Pole three enables internal testing which must be disabled for normal operation. Pole four, in conjunction with pole three, makes the node appear to be busy to other nodes. This condition is used by Elsag Bailey personnel only. Pole five enables the loop idle condition display for the front panel LEDs. If loop one is idle, the group A LEDs will flash on and off about twice per second. If loop two is idle, the group B LEDs will flash. The loop idle display is intended to serve as a warning that a loop integrity problem exists. Pole six enables diagnostic tests that preclude normal NIS module operation. Poles seven and eight determine loop speed and loop mode

Want To Know More About ABB, Contact Us

DSQC227Robot Control Board
DO930S900 I/O Relay Output Module
DO910S900 I/O Digital Output Relay Module
DO820 3BSE008514R1S800 I/O Digital Output Relay Module
CI858K01 3BSE018135R1S800 I/O Drive Bus Interface Kit
CI855K01 3BSE018106R1MBMB 300 Dual Ethernet Port Interface Kit
CI854AK01 3BSE030220R1Profibus DP-VI Communication Module Kit NIB
CI830 3BSE013252R1Communications Interface S800
SD831Power Supply Module
