Allen-Bradley 1756-A17 ControlLogix New

About1756-A17

The Allen-Bradley 1756-A17 is a ControlLogix I/O Chassis-Based Module. It has a 17-slot ControlLogix Chassis, a 6.1W power dissipation, and a 1.8W power consumption. It has dimensions of 29.06 x 6.65 x 5.71 in. and weighs 4.8 lbs. It is horizontally mounted inside the panel and has an open enclosure. It has a maximum Backplane current of 1.5 A at 1.2V DC, 4 A at 3.3V DC, 15 A at 5.1V DC and 2.8 A at 24V DC. For communication, it uses ControlNet or EtherNet/IP networks. The 1756-A17 Standard Chassis includes inherent time-stamping capabilities for SOE applications. The chassis backplane distributes power to each of the modules within the chassis by providing a high-speed communication path between modules. It requires a Bulletin 1492 wiring IFM or an RTB to connect all the field-side wiring. For programming, it uses Studio 5000 Logix Designer Application software. The software includes I/O wizards for quick and easy module configuration. The 1756-A17 Standard Chassis provides easy maintenance with the RIUP feature. For preventing replacement errors, it also offers electronic keying. In case of any system or field side failure, its comprehensive diagnostic feature helps identify the fault. It is compact, cost-effective, and easily compatible with items such as PanelView operator.
