ALLEN BRADLEY 1746-OB16E OUTPUT MODULE SLC 500

About1746-OB16E

The1746-OB16E SLC 500 Digital Output Moduleis an electronically-fused 24V DC signal output module by Allen-Bradley which can be fixed on any available slots in 1746 Chassis and it uses a Removable Terminal Block (RTB). It has an operating voltage range between 10 and 30V DC (source) and draws a backplane current of 0.135A at 5V DC. The1746-OB16Ehas a load-dependent 1ms signal delay time for both ON and OFF mode and it has a maximum output current leakage of 1mA in its OFF state. The minimum current load available on each point is 1mA and it has an inrush current 2.0A on each point for 2ms repeating every 1s at 30 °C (86 °F). The1746-OB16Ehas 0.388W heat dissipation per output point and 7.6W of aggregate heat dissipation on the module. It has an operating temperature bracket of 0-60 °C (32-140 °F) at a relative humidity condition of 5-95% without condensation and it is NEMA ICS 2-230 rated for Noise immunity. The1746-OB16Ehas an operational vibration of 2.5G at 10-200Hz and a shock rating of 30G.
