ALLEN BRADLEY 1746-OB16 OUTPUT MODULE SLC 500

About1746-OB16

The 1746-OB16 has a nominal input current of 0.5A at 30 degrees Celsius and 0.25 A at 60 degrees Celsius for each output point and it has a gross input current of 8A at 30 degrees Celsius and 4A at 60 degrees Celsius per module. It also has a current surge of 3A for 10ms recurring every 1s at 30 degrees Celsius and 2s at 60 degrees Celsius (140 degrees Fahrenheit). The 1746-OB16 provides voltage isolation between the backplane and the outputs tested at 1500 Volts AC and it has a total heat dissipation of 7.6 Watts. It has a UL-A196, CSA, and C-UL Class I, Division 2 Hazardous Environment ratings, and it is CSA and UL-certified. When operational, the 1746-OB16 has a working temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) at 5 to 95% non-condensing humidity surrounding and it is designed to withstand a 30G operational shock and a 2.5G operational vibration at 57 to 200 Hertz.
