Rockwell Allen Bradley 1746-IB8 Input Module SLC 500 Module

About 1746-IB8

The 1746-IB8 SLC 500 Digital DC Input Module by Allen-Bradley is a DC input module in the SLC 500 I/O module series with eight 24V DC current sinking inputs. The 1746-IB8 has an operational voltage range between 10 and 30V DC with its nominal voltage at 24V DC and it has a backplane current of 50mA at 5V DC and of 0.0mA at 24V DC. The maximum signal delay time on each input point of the module is about 8ms for ON mode and 8ms for OFF mode, and the maximum OFF state voltage in the circuit is 5.0V DC. The 1746-IB8 has a maximum OFF-state current of 1mA, and when operational, its nominal input current is 8mA at 24V DC.

SLC 500 System Overview

The Allen-Bradley SLC 500 is a small chassis-based family of programmable controllers, discrete, analog, and specialty I/O, and peripheral devices. The SLC 500 family delivers power and flexibility with a wide range of communication configurations, features, and memory options. The RSLogix 500 ladder logic programming package provides flexible editors, point-and-click I/O configuration, and a powerful database editor, as well as diagnostic and troubleshooting tools to help you save project development time and maximize productivity.
