Allen Bradley 1756-CNBR Communications Bridge

About1756-CNBR

The technical specifications of this module are also similar to the non-redundant module. It can also handle up to 64 bidirectional scheduled and unscheduled connections with other ControlNet devices. Aside from that, up to 20 buffers for unconnected messages can be supported by the module. Also, this is the module needed if your application has 40 to 48 Logix communication connections per communication module and the communication rate is 5 megabytes per second. It also has 99 nodes available..

The current draw for the 1756-CNBRis 970 milliamperes at 5.1 Volts DC and 1.7 milliamperes at 24 Volts DC.Before making your connection, make sure tocheck the tap drop cable for the label indicating the attached segment. This is to make sure that the tap connections will not be accidentally reversed. If not, these reversals will require troubleshooting and the status will be displayed incorrectly.
