Allen-Bradley 1785-L60B PLC - 5 Processor Module

About 1785-L60B

The 1785-L60B has 3 different I/O hardware-addressing modes (2-slot, 1-slot, and half-slot addressing) with the 2-slot mode addressing any mix of 8-point modules, a pair of 16-point modules, and no 32-point module addressing, the 1-slot addressing any mix of 8 or 16-point module, and a pair of 32-point modules, and the half-slot mode addressing any mix of 8, 16, and 32-point modules. The processor module has a maximum of I/O chassis connection of 93 (32 per link) and it communicates via the 25-pin D-shell serial port, which supports standard RS-232 and RS-423 serial interface, a DH+ port for connection to the DH+ network and a remote I/O port (Channel 1B port). The 1785-L60B has an operational temperature range between 0 and 60 0C (32 and 140 0F) around a relative humidity range of 5-95% without condensation, and it is built for an operational shock of 30G and a vibration of 2G at 10 to 500 Hertz. It weighs approximately 1.42 kilograms (3 pounds) and comes in an open-style enclosure, and it is UL, C-TICK, CE, and CSA-certified.
