Allen Bradley 1785-L80B MODULE NEW

About 1785-L80B

On the1785-L80B,the Data Highway Plus (DH+) link can be used on all four existing channels. DH+ communication can be used for data transfer to other PLC-5 controllers or other higher-level components of the control system. The DH+ link canprogrammultiple PLC-5 controllers. On the front panel of the1785-L80Bcontroller, there is a 25-pin connector marked channel 0. This is an optically isolated EIA RS232C port. Channel 0 supports ASCII and DF1 full and half-duplex master and half-duplex slave protocols. On the front panel is a green channel 0 communicationindicator light. Beside channel 0, there are two 8-pin mini-DIN connectors marked as channel 1A and channel 2A, and there is a DH+ programming terminal connection parallel to channels 1A and 2A. There are four three-pin connectorsused as communication ports. These three-pin connectors are used for channel 1A, 1B, 2A, and 2B. All of these ports can function as remote I/O scanners, remote I/O adapters, or as DH+ communication ports. The maximum cable length for the DH+ link depends on thetransmission rate. It is crucial that all devices on a DH+ linkcommunicate at the samerate. That length goes from a maximum 3048m for speed 57.6 kilobits per second, to 762m for a speed of 230.4 kilobits per second.The 1785-L80Bhas several indicators on the front panel for easy interaction. Indicatorsdisplayvarious controller statuses. The indicator marked BATTdisplays the status of the battery. The indicator marked PROC indicates the current controllermode, it is green when the controller is in RUN mode, and red when something is wrong. The FORCE indicator isamber when the I/O forces are enabled. The COMM indicator is linked with channel 0's communication status. The indicator is green when the channel is communicating. All four communication channels: 1A, 1B, 2A, and 2B, have dedicated status indicators.
