Allen Bradley PanelView 2711-T10G20 New

About 2711-T10G20

The Allen-Bradley 2711-T10G20 is a PanelView Standard 1000 touchscreen terminal. It is a grayscale terminal that has an EtherNet/IP communication port and an RS-232 printer port. The 2711-T10G20 is AC-powered and has a non-volatile memory of 1008 KB and a RAM of 310 KB. It has a display size of 10.1 inches and is enclosed in a NEMA Type 12/13 or 4x enclosure. This terminal has an input voltage range of 85 to 264 Volts AC and 47 to 63 Hertz. It also has a 256 KB memory for storing files, applications, and other data. Use the 2711-ND3 PanelBuilder 32 software to configure this terminal. The 2711-T10G20 has an electronic circuitry that is powered by an external power supply voltage of 85-264VAC with frequency of 43-63 Hz. It has a power consumption of 55 VA, maximum and rated Heat dissipation of 39 W (132 BTU/HR). Install this operator terminal to an enclosure rated NEMA Type 12/13, 4X (Indoor use only) IP54, IP65. Appropriate heating and cooling devices may be used to maintain the required operating temperature of 0…55 ° C (32…131 ° F). Similarly, install shock and vibration limiting components and devices to limit shock and vibration within 15 g and 2 g up to 2,000 Hz respectively.
