Allen Bradley1769-OW8 Module CompactLogix
About1769-OW8
The Allen-Bradley 1769-OW8 is a compact DC/AC relay contact module. It belongs to the 1769 Compact I/O module series which can be used with Allen-Bradley CompactLogix controllers and MicroLogix 1500 controllers. For I/O expansion applications through remote I/O systems, this module is compatible for use with the 1769-ADN DeviceNet adapter, or with 1769-AENTR Ethernet adapters.
The 1769-OW8 is certified by the CE and c-UL standards. The 1769-OW8 features Eight (8) normally open outputs. The operating voltage ranges are 5 to 265 Volts AC and 5 to 125 Volts DC. Both the on delay and the off-delay time are 10 milliseconds while the module’s current draw at 5.1 Volts DC is 125 milliamps and at 24 Volts DC, is 100 milliamps. The maximum heat dissipation is 2.83 Watts.
There are different contact ratings for the 1769-OW8 module at different voltage ratings. At 120 to 240 Volts AC, the module is rated at 2.5 Amps maximum continuous current. At 125 Volts DC, the maximum continuous current rating is 1.0 Amps and at 24 Volts DC, the maximum continuous current rating is 2.0 Amps. The recommended wire type to be used for termination on the module is Copper 90 degrees Celsius rated wire. The rated torque for the terminal and retaining screws are 0.68 Nm and 0.46 Nm, respectively. The approximate weight of the 1769-OW8 is 280 grams. The dimensions of the module are 118 x 35 x 87 millimeters. The module takes up 1 slot in the chassis. The power supply modules compatible with the 1769-OW8 are the Allen-Bradley 1769-PB4, 1769-PA2, 1769-PB2, and the 1769-PB4 modules.
