NEW ALLEN BRADLEY 1756-L65 SER B CONTROLLOGIX CPU

Description

The Allen-Bradley 1756-L65 is a Series B ControlLogix controller. It has a built-in RS-232 serial port available, as well as auser memory for data and logic of 32 MB and an I/O memory of 478 kb. You can also installan optional nonvolatile memory storagewith this controller. However, what can be installed isonly the 128 MB CompactFlash 1756-CF128memory card. It also has a battery that can be replaced but only when needed. The battery compatible with this controller is only the 1756-BA2 lithium battery. The compatible ControlLogix chassis with this controller are 1756-A4, 1756-A7, 1756-A10, 1756-A13, and 1756-A17.

It has a maximum analog I/O of 4000 and a maximum digital I/O, as well as a maximum total I/O, of 128,000. It has a current draw of 1200 mA at 5.1V DC and 14 mA at 24V DC. Its power dissipation is 3.5 W and thermal dissipation is at 11.9 BTU/hr. It also has a continuous isolation voltage of 30V. This controller has also been type tested for 60 s at 720 V DC.

The 1756-L65 controller has an operating temperature that ranges from 0 to 60 Degrees Celsius, as well as a storage temperature ranging from -40 to 85 Degrees Celsius. It also has a maximum surrounding air temperature of 60 Degrees Celsius and a noncondensing relative humidity range of 5% to 95%. The controller has a vibration of 2 g at 10 to 500 Hz, an operating shock of 30 g, and a non-operating shock of 50 g.

Same with other ControlLogix 5560, the 1756-L65 alsohas three main controller tasks, namely 100 programs/task, 32 tasks, and event task: all event triggers. Communication options available for this controller are DeviceNet, ControlNet, EtherNet/IP, Remote I/O, Data Highway Plus, SynchLink, and Third-party process and device networks. Serial port communication is also present with this controller, and these are ASCII, DF1 radio modem, DF1 full/half-duplex, Modbus via logic, and DH-485. It has the ability to support as much as 250 controller connections.

It should be noted that thescanning time of this controller may be slowerthan other ControlLogix 1756-L6x controllers, given that the same project has been loaded to these controllers.

FAQ:

1.Is the part new? Yes, 100% Original brand new

2.How is the package? Original factory seal packed

3.What is the lead time? In stock: 1-3 working days

4.What is the MOQ: 1pcs

5.What is the payment term: TT and Western Union, other negotiable

6.Where the item ship from? Xiamen

7.What is the warranty time? One year

8. How to delivery the PLC Parts? Kindly tell us your address,we check best cost for you Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
