Allen-Bradley PLC CompactLogix 1769-L30

Description

TheAllen-Bradley1769-L30 compact Logix processor modulecan support up to 16 I/O modules with 2 expansion cables on a maximum of 3 I/O banks. Each I/O bank requires its own power supply, and only one1769-L30 processor moduleor any Logixcontroller module can be connected to a compactLogix system at a time. The1769-L30can be used anywhere in an industrial area. The1769-L30can communicate with any device through an RS-232 port with either a 1747-CP3 or a 1756-CP3 programming cable. It has a user memory of 256 KB and runs on RS5000 software.

The1769-L30has a current backplane of 800 mA at +5V DC and 0 mA at +24V DC. It has an operational temperature range between 0° to 60°C (32° to 140°F), at a 5% to 95% non-condensing relative humidity. The1769-L30has a key switch on the front panel for controlling the operation mode. The1769-L30has the following key switch functions (RUN, PROG, REM) which can either be used to run the program, enable or disable outputs, or change between the remote program on the controller. The1769-L30can be mounted using either a panel mounting or a DIN rail. It has an operationalvibration of 10G at 500HZ and a shock rating of 30G.
