Allen-Bradley 1762-L40BWA Micrologix 1200 New In Stock

Description

The 1762-L40BWA is a Programmable Logic Controller (PLC). This controller is a MicroLogix 1200 by Allen-Bradley. It features a total of Forty (40) Input and Output channels which specifically consists of Twenty-Four (24) Discrete inputs and Fourteen (14) Discrete Outputs. The input channels are designed for interfacing input devices that carry 24VDC via sinking and sourcing wiring configuration. The outputs are contact outputs that are rated for 25-125 VDC or 120 - 240 VAC with mechanical life of 20,000,000 cycles and rated for a minimum of 10A load. This controller has an integrated 8-pin Mini DIN RS232 communication port that supports DH-485, DF1 Full and Half Duplex, Modbus Master and Slave and ASCII protocols. DF1, ASCII and Modbus in this controller operates in peer-to-peer configuration. Converters may be used to multiplex the serial port to allow communication to multiple devices. These converters may be an RS223 to Ethernet converter of RS232 to RS485 converter. DH-485 is ideal for connecting to a network bus with the use of an external converter such as a 1761-NET-AIC.

Allen Bradley Main Products:

1. SLC500:1747/1746 series 2.MicroLogix: 1761/1763/1762/1766/1764 series 3.CompactLogix: 1769/1768 series 4. The ControlLogix: 1756/1794/1760/1788 series 5. PLC-5:1771/1785 series 6.2711,2711P PanelView man-machine interface, touch screen, operation panel 7.22A,22B, 20 small frequency converter,150 soft starter 8. ProSoft: MVI69 / PS69 / MVI56 / MVI94 / MVI71 / MVI46/3150 9. ICS TRIPLEX: T8431 / T8461 / T3401 / T8310
