Allen Bradley PanelView Plus 1000Operator Terminals 2711P-T10C4D2

Description

The 2711P-T10C4D1 has a 10.4 inch colored display screen and permits operator interaction through the analog resistive touchscreen interface, designed up to 1 million actuations with an actuation force of 10-110 g. The embedded memory amounts to 128 MB Random Access Memory (RAM) and 128 MB Flash Memory. This operator terminal is powered by an external 24VDC power supply voltage. The nominal DC input voltage of the 2711P-T10C4D2 terminal is 24 Volts DC and its input voltage ranges from 18 to 32 Volts DC. It also has a maximum DC power consumption of 70 Watts, with 2.9 Amps of current at 24 Volts DC, and a typical DC power consumption of 39 Watts, with 1.6 Amps of current also at 24 Volts DC. This terminal has an AC input voltage ranges of 85 to 264 Volts AC at 47 to 63 Hertz. Its maximum AC power consumption is 160 VA, while its typical AC power consumption is 65 VA. The 2711P-T10C4D2 terminal also has an operating temperature range of 32 to 131 degrees Fahrenheit, a storage temperature range of -4 to 158 degrees Fahrenheit, and a non-condensing relative humidity of 5 to 95%. Its operating shock is 15 G at 11 milliseconds and its non-operating shock is 30 G at 11 milliseconds. Users can configure the 2711P-T10C4D2 terminal using the FactoryTalk View Machine Edition (ME) software. It ships with a firmware ranging from versions 3.13 to 4.48. Communication ports for this terminal are an RS-232 port and an EtherNet port.
