Allen Bradley 2711C-F2M PanelView C200Brand New And Original

Description

The Allen-Bradley 2711C-F2M is a PanelView C200 component. This operator terminal is a low-cost Human Machine Interface (HMI) device that is ideal for use in simple and small industrial application for controlling machines or processes. This device is a 2-inch screen HMI with an integrated development environment residing within its memory. The 2711C-F2M is a operated, through the embedded keypad which is made of Four function keys (F1…F4) Up, down, left, right and Enter keys. The 2-inch screen is of Monochrome transflective STN passive matrix type with viewing area of 49 x 14 mm (1.93 x 0.55 in.) and resolution of 122 x 32. It has a non-replaceable backlight designed for continuous operation which may be operated up to 50,000 hours. It is equipped with a variety of serial interfaces such as Two (2) RS232 communication ports that is compatible with DH485 and DF1 protocol and an RS485 communication port for multi-node communication through daisy-chain architecture. The development software used to configure HMI operation is the DesignStation software which is installed within the HMI and accessed via the web browser such as Firefox 3.0, Internet Explorer 7 or 8 Emulator available. This software is activated and licensed by Rockwell Automation.

About us

Our office is located in Xiamen Fujian, China, cooperate with original manufacturer directly; Equipped with a professional sales team, own engineer for technical support and good after-sale service;Large inventory with original product quality for fast delivery. These help us become as a strong supporter of our clients: providing solution for the end-user, and also ensuring profits for the re-seller.FAQ:
