1769-IF4 Allen Bradley CompactLogix Analog Input Module

Description

The 1769-IF4 is an analog input module that is used with Allen Bradley’s MicroLogix 1500 and 1769 CompactLogix family of controllers. This module is configured using RSLogix 500 programming software when used with MicroLogix 1500 and RSLogix 5000 / Studio 5000 is used with 1769 CompactLogix controllers. The Four (4) input channels of this module are individually configured to receive current and voltage signals at ranges of 0-21 mA; 3.2 - 21 mA for Current and ±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC for Voltage. Nominal current signals are 0-20 mA and 4-20mA and voltage signals available are +/10VDC, 1-5VDC, 0-5VDC, 0-10VDC. This module is integrated with an Analog to Digital (ADC) circuit with conversion type of Delta-Sigma. The module’s conversion resolution are 14 bits or unipolar and 14 bits plus sign or bipolar. The data processed by the module can be configured with data formats as engineering units, scaled for PID, percent range and raw data.
