Allen Bradley 1769-PA2 Power Supply

Description

The Allen-Bradley 1769-PA2 is a CompactLogix I/O power supply. This power supply is primarily used as I/O power supply, installed in a CompactLogix assembly or to an expansion I/O bank. It provides power to the modules attached on both direction of the module installed to a system in consideration to the required Power Supply distance rating. When installed along a CompactLogix controller assembly, Compact I/O modules may be installed on both sides of the power supply as the power supply can supply power on both directions as well as the Power supply distance rating may also be counted in both ways. Up to Eight (8) 1769 modules may be installed on both sides of this power supply. Required input voltage range for this power supply is 85-265VAC with frequency of 47-63 Hz. It has a current capacity of 2.0A at 5VDC and 0.8A at 24VDC. This module is equipped with an internal fuse which may be replaced with Wickmann 19195-3.15A or Littelfuse 02183.15MXP. This power supply has a dimension of 118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.) and an approximate weight of 525 g (1.16 lb). As standard to CompactLogix platform, this power supply module also support installation to a DIN or directly to a mounting plate.
