Allen-Bradley1769-L19ER-BB1BCompactLogix 53701MB Memory Controller

Description

TheAllen-Bradley 1769-L19ER-BB1Bis part of the CompactLogix 5370 L1 Programmable AutomationControllers (PAC) series. It offers high-performance motion solutions in a compact design and cost-efficient package. It features dual EtherNet ports and comes with an integrated switch that allows support for traditional star, linear, and DLR (Device Level Ring) topologies. DLR capability enhances network resiliency where individual parts can be replaced without compromising production.

The1769-L19ER-BB1B Controllerhas one USB port, supports local expansion modules, and allows the use of an SD (Secure Digital) card for nonvolatile memory. It uses a POINT I/O (1734) backplane and can accommodate up to 8 I/O expansions. The1769-L19ER-BB1B’sembedded I/O DC digital modules consist of 16 inputs and 16 outputs. It features a maximum capacity of 8 EtherNet nodes and a user memory of 1 MB. This controller ships with a 1GB 1784-SD1 card but can support a 2GB SD card (1784-SD2).

The1769-L19ER-BB1B DIN Rail Mount PAChas a 24V DC input, isolated embedded power supply with 10-28.8V DC operating voltage range. Its power terminal accepts 1 or 2 wires size 0.051-3.31 mm2 (30 and 12 AWG) with solid or stranded copper wire rated at 75 °C (167 °F) or greater and 1.2 mm (3/64 in.) insulation. Its minimum line requirement (VDC) is 30VA.
