1715-TADIB16D Allen Bradley PLC 1715 Redundant I/O

Description

The 1715-TADIB16D is an Allen-Bradley redundant I/O module termination assembly. The 1715-TADIB16D is classified under the 1715 series of Allen-Bradley redundant I/O modules and it features the wire size 22 to 16 AWG. The 1715-TADIB16D has the screw torque of 0.5 N-m and it features the termination assembly type of digital input duplex. The 1715-TADIB16D comes with 133 grams of shipping weight and shipping dimensions of 132 x 84 millimeters. The operating voltage range for the 1715-TADIB16D is rated as 260 mA at 18 to 32 Volts DC. The power dissipation for the 1715-TADIB16D is 7.2 Watts maximum for the module and termination assembly combination.

The isolation voltage for the 1715-TADIB16D is 50 Volts continuous with the basic insulation type. The wiring type for the 1715-TADIB16D is 2-wire on the signal ports and it comes with a fuse type rated at 50 mA or with the 125 Volts Type T fuse type. The operating temperature range for the 1715-TADIB16D is -25 degrees Celsius to 70 degrees Celsius. The non-operating temperature range for the 1715-TADIB16D is -40 degrees Celsius to 85 degrees Celsius. The relative humidity range for the 1715-TADIB16D is 5 to 95%, non-condensing, while the module also features a vibration rating of 2 G at 10 to 500 Hertz. The shock resistance during operation while the module is installed on a DIN rail mount is 25 G, and while the device is installed on a panel, the resistance rating is 30 G. The 1715-TADIB16D features several internationally recognized standardization certifications for safety standards as well as for other criteria.
