Good Price High Quality In Stock 1715-TASIF16

Description

The 1715-TASIF16 is a redundant I/O termination assembly module. The module fits into a small installation area. The device has an open enclosure with the IP20 rating. The IP20 rating indicates that the device is not water-resistant. The device should be kept inside a shielded bag when it is not in use. The power dissipation in this type of I/O termination assembly is 4 Watts and the field loop dissipation is a maximum of 0.075 Watts per field loop. The 1715-IF16 module is also supported by this module. This 16-channel module has basic insulation from I/O ports to the backplane but no insulation is present in between the individual I/O ports. The 1715-TASIF16 is enabled with an RFI suppression device. The connecting cables used in this module are made of stranded copper wire and it weighs only 133 grams.

The 1715-TASIF16 module can be mounted using a DIN rail. It can withstand a maximum temperature of 158 degrees Fahrenheit during its normal operation. A 95% humid environment is the maximum non-condensing humidity level for this module. The terminal assembly module is fitted and tested at 500 Volts AC for 60 seconds. The temperature required to run this assembly ranges from -13 degrees Celsius to 158 degrees Celsius. The 1715-TASIF16 has a screw torque rating of 0.5 N-m. It has an input resolution of 0.0039 milliamps/cnt. This terminal assembly module has been certified with the UL, CE, C-Tick, Ex, and KC standards. These certifications ensure that the industrial safety and environmental requirements in different regions are all met. It also meets multiple industrial emission standards. For communication purposes, it comes with a shielded RJ45 connector. The device should be properly grounded before installation. The airflow should be enhanced with good ventilation and the environment should be free from corrosive materials, dirt, and oil.

Our Advantage

1. Professional Service:

With the help of professional Technology team, we provide the best sales and maintenance as well as the long-term warranty.

2.Enough Inventory

We have a large stock3. Superior Marketing foresight.

Follow the Network development with the professional Global Marketing Analysis, we open Real Store and online shop together to offer clients best products and competitive price in short time.

4.Win-Win BusinessTheory

Our company theory is fast in accessories supply, most competitive in price, most convenient in Tech Consultation.

Allen Bradley Main Products:

1. SLC500:1747/1746 series 2.MicroLogix: 1761/1763/1762/1766/1764 series 3.CompactLogix: 1769/1768 series 4. The ControlLogix: 1756/1794/1760/1788 series 5. PLC-5:1771/1785 series 6.2711,2711P PanelView man-machine interface, touch screen, operation panel 7.22A,22B, 20 small frequency converter,150 soft starter 8. ProSoft: MVI69 / PS69 / MVI56 / MVI94 / MVI71 / MVI46/3150 9. ICS TRIPLEX: T8431 / T8461 / T3401 / T8310

More Products
