lowest PriceHigh Quality In Stock 1746-OG16

Description

The Allen-Bradley 1746-OG16 has voltage category of 5V DC TTL signal input (sinking). This module has Sixteen (16) TTL outputs and. The operating voltage of the 1746-OG16 is 4.5-5.5V DC with a maximum 50 mV peak-to-peak ripple. The 1746-OG16’s backplane current at 5V is 0.18A with backplane current at 24V is 0A. The Off-state voltage of this module is from 4.5-5.5 V DC. The maximum Off-state leakage current of this module is 0.1 mA. The continuous current per point is 24 mA. The 1746-OG16’s operating temperature is from -13-140 deg. Fahrenheit while the non-operating temperature is from -40-185 deg. Fahrenheit at 5-95% relative humidity without condensation. The operating vibration of this module is 2g at 10-500 Hz and 2.5 g at 57-2000 Hz while the operating shock is 30g. The Allen-Bradley 1746-OG16 is intended for industrial environments with a pollution level no higher than Pollution 2 (as defined in EN / IEC0664-1). The enclosure should be accessible only by the included appliance. Do not disconnect equipment unless power has been removed and if the area is known to be dangerous because an electric arc will be created. This output module, similar to the input module, has an inverted logic. To properly operate a TTL module, a NOT instruction is needed to be negated the naturall

Our Advantage

1. Professional Service:

With the help of professional Technology team, we provide the best sales and maintenance as well as the long-term warranty.

2.Enough Inventory

We have a large stock3. Superior Marketing foresight.

Follow the Network development with the professional Global Marketing Analysis, we open Real Store and online shop together to offer clients best products and competitive price in short time.

4.Win-Win BusinessTheory

Our company theory is fast in accessories supply, most competitive in price, most convenient in Tech Consultation.

Allen Bradley Main Products:

1. SLC500:1747/1746 series 2.MicroLogix: 1761/1763/1762/1766/1764 series 3.CompactLogix: 1769/1768 series 4. The ControlLogix: 1756/1794/1760/1788 series 5. PLC-5:1771/1785 series 6.2711,2711P PanelView man-machine interface, touch screen, operation panel 7.22A,22B, 20 small frequency converter,150 soft starter 8. ProSoft: MVI69 / PS69 / MVI56 / MVI94 / MVI71 / MVI46/3150 9. ICS TRIPLEX: T8431 / T8461 / T3401 / T8310
